Product Details

• Basic Information




  manufacturer	Dongfeng Motor
  brand	Dongfeng D9
  Vehicle Type	Sewage Suction Truck
  Engine model	YCS04200-68/B6.2NS6B230
  Engine power (KW)	147/169
  Energy type	Diesel
  Emission standard	China VI
  Tire Specification	295/80R22.5 18PR
  Cabin Capacity	2/3 people
  Top speed (km/h)	105/89
  Length x Width x Height (mm)	7960*2500,2550*3750,3700,3650
  Vehicle model	KLF5182GXWE6




  Wheelbase (mm)	4500
  tank material	high-quality carbon steel (6mm thick)
  tank dimensions (straight length × diameter, mm)	4600x1800
  working mode	tank lifting and self-unloading
  effective tank volume  (m3)	13
  Curb weight (kg)	9880
  Maximum total mass (kg)	18000
  Rated load weight（kg）	7925,7990
  hydraulic system pressure (mpa)	18
  sewage suction pipe	one 8m long suction pipe
  pump	10-ton vacuum pump / sk-12 water circulation pump
  additional configurations	visual device for sewage, oil-water separator, anti-overflow valve, etc.

• Product Positioning



• Application Scenarios

  Environmental Emergency Response
  During hazardous pollution incidents, it efficiently extracts leaked oils, chemical solutions, and other liquid contaminants to prevent soil infiltration or waterbody contamination, enabling sealed hazardous waste transport. In natural disasters like storm-induced flooding, it provides rapid municipal emergency drainage.
  Sewer Sludge Suction
  Capable of handling various liquid and semi-liquid wastes, even suspended debris such as sludge, small bricks, and gravel. The sewage suction truck consists of a chassis, power take-off (PTO), drive shaft, vacuum pump, pressure tank, hydraulic system, pipeline network, vacuum pressure gauge, inspection window, and cleaning facilities. Equipped with a high-power vacuum pump and premium hydraulic system, the tank features a one-time die-cast head, rear-opening design, and dual-cylinder self-dumping mechanism for efficient waste extraction.
  Manure Pit Sewage Suction
  Incorporates three functions: vacuum suction, pressurized discharge, and gravity discharge. Its innovative pipeline design ensures easy installation and maintenance, significantly simplifying operations. The tank is constructed from high-quality carbon steel or stainless steel with a one-time roll-forming process for enhanced durability. A transparent viewing tube allows operators to monitor fluid levels in real time, preventing overflow.
  Wastewater Treatment
  Suitable for extracting industrial wastewater, with an anti-overflow valve to prevent spillage. The suction and discharge pipes are made of PVC, offering wear resistance, cold resistance, anti-aging properties, non-toxicity, high negative-pressure tolerance, and fracture resistance for extended service life.
